icon AEROSPACE RELEASE MATERIAL

S. K. International offers aerospace release materials from one of the most reputed mills in Europe, having modern production facilities, vast range of product range, and host of work & product approvals, thereby becoming a prominent supplier of aerospace release material during the past 10 years.

  We can offer and deliver most of the commonly used aerospace steel, stainless steel grades to meet your requirements.



» Stainless Steel
» Aluminum- Alloy
» Nickel- Alloy
» Titanium- Alloy

Approvals / Certificates
The exceptional quality requirements of the aerospace industry, to ensure optimal product quality and reproducibility, has necessitated that the supplying companies be extensively approved. The approvals take place at national level, the EN 9100 and Nadcap approvals for instance, and are reinforced by the individual company approvals. In most cases the company approvals, which primarily evaluate the quality management systems, are supported by the material qualification programmes in which the ultimate quality of the individual material grades is accessed.

A list of some of the major quality approvals which are held by the Deutsche Edelstahlwerke can be seen as below
•  Airbus Germany •  Airbus UK
•  EADF Aerospatiale Matra Airbus •  Rolls Royce
•  Eurocopter •  Pfalzflugzeugwerke
•  Turbomeca •  Singapore Technology Centre
•  Bombardier / Shorts •  Pratt & Whitney
•  Lord Aerospace •  Westland Helicopter
•  Hawker Beechcraft •  BAE Systems
•  Messier Dowty •  Liebherr
•  GKN Aerospace •  SKF Aerospace
•  Premium Aerotech •  Aircelle*
•  Goodrich* •  Nadcap (AS7102)
•  ISO 9001:2000 •  EN 9100:2003
•  DIN EN ISO/IEC 17025:2005
* Material approval

Our product range for aerospace grades (steel)

Billets 50 - 400 mm square
Bars

2 - 500 mm round

(hot tolled or forged, rough peeled, peeled, drawn, ground)
20 - 105 mm square
Wire Rod 5.5 mm - 27 mm round
Wire 0.8 mm - 22 mm round
Flat Bars 20 mm x 5 mm - 350 mm x 120 mm
back to top

Chemical composition
Material No. Short Name Nat. Specification Designation
1.3505 100 Cr6 USA AMS 6440
1.4006 X12Cr13 D DIN/EN 10088-3
    AISI 410
  USA AMS 5613
1.4014 X20Cr13 D LW 1.4014
1.4044   GB BS 3S62 S 62
    WL. 1.4044 Part 1
X22CrNi17 D DIN 65038 1.4044; 1.4044
1.4418   F AIR 9160/9161 Z15CN17.03
    BS 7S80 7S80
  GB BS 5S100/1993
X4CrNiMo16-5-1 F AIR 9160/9161 Z8CND 17.04
1.4542 X5CrNiCuNb16-4 USA AMS 5643 AMS 5643
1.4544   F AIR 9160
1.4545 X5CrNiCuNb15-5 D WL. 1.4545 Part 1 1.4545
1.4546   USA AMS 5659 Type I AMS 5659
  USA AMS 5659 Type II AMS 5659
X5CrNiNb18-10 D WL. 1.4546 Part 1 1.4546
1.4548     BS 2S130
  GB BS 5S100/1993 2S130
  USA AMS S5646 AMS S5646
X5CrNiCuNb17-4-4 D WL. 1.4548 Part 1 1.4548
1.4939   USA AMS 5622 AMS 5622
  X12CrNiMoV12-3 D WL. 1.4939 1.4939
1.5815   F AIR 9160
  GB   S151
  USA AMS 5719 Jethete M 152
36CrNi6-4 F AIR 9160/9161 35NC6
1.6562 40NiCrMo8-4 USA AISI 4340 AMS 6414
1.6657 14NiCrMo13-4 F AIR 9160/9161 16NCD13
1.6722/23   USA SAE 9310
  USA AMS 6265
  F 16 NCD 17
    D ZFNL9207
  GB BS S156/S82
32NiCrMo13-4 GB BS 2S97+ S154+S140 2S97/S154/S140
1.6745     BS 5S100/1993
40NiMoCr10-5 GB BS 2S98+5S99 2S98/5S99
1.6747     BS 5S100/1993
30NiCrMo16-6 F AIR 9160/9161 30NCD16, 35NCD16
1.6928 41SiNiCrMoV7-3 USA AMS 6419 300 M
1.7220 34CrMo4 F AIR 9160/9161 35CD4
1.7223 41CrMo4 D SEL 7223
1.7734   USA SAE 4120 (AMS 6382)
15CrMoV6-9 D WL 1.7734 1.7734
1.7765   F AIR 9160/9161 15CDV6
32CrMoV12-10 D WL 1.7765
1.8515   F AIR 9160 Bl. 89 32CDV13
  31CrMo12 D SEL 8515
1.8523   GB BS 4S106 BS 4S106
  39CrMoV13-9 D SEL 8523
    F   40CDV12
    GB BS 3S132 3S132
back to top


Several common aerospace grades are available from stock (steel)
Diameterin mm 1.4044.6 (S80) 1.4546.9 (S130)

1.4545.4

15-5PH (H1025)

1.4548.4

17-4PH (H1025)

1.4542.9

17-4PH Cond. A
6     Ο Ο
8   Ο Ο Ο
12.7   Ο
16   Ο Ο Ο Ο
20 Ο + Ο Ο
22   + Ο Ο
22.23 Ο
25 Ο + Ο Ο +
28   +
30   + Ο Ο +
32 Ο + Ο Ο
35         +
36 Ο   Ο Ο
40 Ο + Ο Ο +
44.45   +
45   + Ο Ο +
47.63   +
50 Ο + Ο Ο +
55   + + + +
60 Ο + + + +
65     Ο Ο
70 Ο + Ο Ο +
76.2   +
80   + Ο Ο +
82.55 + +
85     + +
88.9 + +
90     Ο Ο +
95     + +
95.25 + +
100   + Ο Ο +
101.6 + +
105     + +
107.95 + +
110     + + +
114.3 + +
115     + +
120     + + +
120.7 + +
125   +
130     + + +
140     + + +
150         +
155     + +
160     + + +
170     + +
180         +
190     + +
200     + + +
o = peeled/drawn bright bar LN 668        + = LN 1013 rough peeled
back to top

Aluminium alloys for aerospace

Sheets / Plates

  Sheets thickness < 7 mm Plates(thickness ≤ 7 mm)
Grade 2024 5086 2024 2618 A 7010 7175
Temper T 3 T 3 Clad H 111 T 351 T 851 T 7451 T 7351
Specification

AIR
ASNA
QQA
WL
DAN
CR

AIMS

9048
3010
250 / 4
-
-
-

-

9048
3012
250 / 5
-
-
-

-

9048
3044
-
-
-
-

-

9048
3011
250 / 4
3.1354
422
1.1.0.36

03.02.004.02

9048
3355
-
-
-
-

-

-
3098
-
-
-
-

-

9048
3050
250 / 12
3.4364
422
-

-

Round bars

Grade 2024 2618 A 5086 6061 7175
Temper T 3 T 351 T 3511 T 6 / T8 T 8511 H 111 T 6 T 73511
Method of production Extruded Drawn Extruded Extruded Extruded Drawn Extruded Extruded Extruded
Specification
AIR 9049 9049 9049 9049 9049 9049 9049 9049 -
ASNA 3182 3058 3351 - 3357 3015 3018 3277 3388
EN 2004 2704 2318 - - - - - 4293
LN - 1798 1799 - - - - - -
NCT 10-235-03 MD - - - - - 10-241-03 MD
CCT LA 279 - - LA 373 LA 380 -
back to top


Nickel alloys for aerospace and severe corrosion resistance

Grade
France / UK Alloy 200/201 Alloy 400 Alloy 600 Alloy 601 Alloy 800 HT
Deutschland 2.4066 / 4068 2.4360 2.4816 2.4851 1.4876
Europe Ni 99-2 / LC-Ni 99 Ni Cu 30 Fe Ni Cr 15 Fe Ni Cr 23 Fe X 10 Ni Cr Al Ti 32-i
USA (UNS) N 02200 / N 02201 N 04400 N 06600 N 06601 N 08811
Specification
ASTM



B 160

B 162

B 161		 B 164

B 127

B 165		 B 166

B 168

B 167		 -

B 168

B 166		 B 408

B 409

B 407
Heat treatment condition A A A A A
Round bars Ø 6 -> 200 mm Ø 6 ->200 mm Ø 6 -> 200 mm Ø 6 ->50 mm Ø 12 -> 160 mm
Sheets, plates Thick0.5 -> 6 mm

Thick 0.5 -> 6 mm

Thick0.4 -> 25 mm

Thick1 -> 8 mm

Thick1 -> 20 mm
Pipes Please contact us Please contact us Please contact us Please contact us Please contact us
A : annealed
  Ronds  Hot rolled plates     Cold rolled sheets    Pipes

Nickel alloys for aerospace and severe corrosion resistance

Grade
France / UK Alloy 625 Alloy 718 Alloy 825 Alloy C 276 Alloy K 500
Deutschland 2.4856 2.4668 2.4858 2.4819 1.4375
Europe Ni Cr 22 Mo 9 Nb Ni Cr 19 Nb Mo Ni Cr 21 Mo Ni Mo 16 Cr 15 W Ni Cu 30 Al
USA (UNS) N 06625 N 07718 N 08825 N 10276 N 05500
Specification

AMS

DMD

 ASTM

Others



5666
-

B 446

B 443

-

5662

424-22

-
-

-

-

-

-

B 424
-

-

-

B 574

B 575
-

-

-

-

-
QQN 286
Heat treatment condition A A A A A
Round bars

Ø 20 -> 150 mm(1)

Ø 12 -> 100 mm(2)		 Ø 10 -> 200 mm   Ø 16 -> 200 mm Ø 20 -> 130 mm
Sheets, plates

Thick0.6 -> 6 mm



Thick0.5 -> 5 mm

Thick1 -> 6 mm



(1)  AMS 5666
(2)  ASTM B 446
A : annealed
  Ronds  Hot rolled plates     Pipes
back to top

Titanium and products for surgical implants

Grade
France T40 TA 6 V
Deutschland 3.7035 3.7164
UK - TA 11 / TA 12
USA Grade 2 Ti 6 Al 4 V / Grade 5
AECMA - TI-P 64001
Specification
Air - 9183 -
ASNA - 3307 -
DMD - 776-24 -
WL - 3.7164.1 3.7164.1
BS - 2 TA 11 / 2 TA 12 TA 56
AMS - 4928 4911
Pr EN - 3310 / 3311 -
Others ASTM B 348 ASTM B 265 MIL-T-9047 MIL-T-9046 / ASTM B 265
Product form
Heat treatment condition A A A A
Size range Ø 16 -> 250 mm

Thick 0.5 -> 40 mm

 Ø 15 -> 300 mm

Thick 4 -> 25 mm
back to top
